Plastazote® LD45 is a closed-cell, cross-linked polyethylene foam with a nominal density of 45kg/m3.
Part of the Zotefoams Azote® range, LD45 foam offers the optimal balance of durability, cushioning, and ease of fabrication. Compared to lower-density grades (such as LD24 or LD33), LD45 is preferred when superior structural integrity, better shock absorption, or a more precise finish is required. It also retains its shape and thickness better under sustained, heavy loads (reduced creep). As such, Plastazote® LD45 is the best all-around grade for applications requiring a balance of protective cushioning and structural support.
At Polyformes, we are official distributors of the full range of Zotefoams materials. Our in-house equipment allows us to cost-effectively supply LD45 foam sheets at the exact size and thickness you require, or convert them into packaging or other foam products as required.
The values provided in this product information represent data gathered from random samples of Zotefoam’s production of Plastazote® HD110 foam and represent typical data. These are given to the best of our knowledge and should be considered as guidance for selecting a suitable grade for a given application. Please contact our foam experts for further advice if required.
A summary of key information for Plastazote® HD110 foam material is as follows:
| Property | Test Standard | Typical Value |
|---|---|---|
| Apparent Density Skin/Skin | BS EN ISO 7214:2012 | 110 kg/m³ |
| Cell size (diameter) | Internal | 0.9 mm |
| Compression stress-strain (25%) | BS EN ISO 7214:2012 | 780 kPa |
| Compression stress-strain (50%) | BS EN ISO 7214:2012 | 976 kPa |
| Tensile strength | BS EN ISO 7214:2012 | 2376 kPa |
| Tensile elongation | BS EN ISO 7214:2012 | 85 % |
| Compression set (25% comp., 22hr, 23°C) | BS EN ISO 7214:2012 (25mm cell-cell) | 16 (½ hr recovery) |
| Compression set (25% comp., 22hr, 23°C) | BS EN ISO 7214:2012 (25mm cell-cell) | 11 (24 hr recovery) |
| Tear strength | BS EN ISO 8067:2008 Method B | 13630 N/m |
| Shore hardness (OO scale) | BS EN ISO 868:2003 | 91 |
| Max operating temp* | Internal | 125 °C |
| Water absorption | ISO 2896:2001 Ed3. | Less than 2% |
*Please see datasheet for full details.
Download the datasheet (PDF format) for full technical details.
Please note that due to individual display settings, the colours you see on your screen may vary slightly from the actual material colour.
Black
Dark Grey
Grey
Silver
Pale Grey
White
Navy
Blue
Teal
Violet
Mauve
Cream
Healthcare
Pink
Red
Orange
Yellow
Gold
Jaguar
Green
Jade
Spring
Lime
Olive
Polyformes can split/skive, laminate and butt-weld Plastazote® material to the specific dimensions you require. You can also select skin or cell finishes. MOQs may apply to certain size/material options.
Please get in touch with a member of our team to discuss your requirements.
Plastazote® HD110 foam sheets are suitable for conversion using the following processes:
The Plastazote® HD range of foams provide increased rigidity, higher temperature resistance, and improved moldability compared to low-density (LD) grades, making them more suited to a range of specific applications. Please note, however, that this list is not exhaustive – if you cannot see your intended application, please get in touch to discuss your options with our foam experts.
